Burrows-Wheeler Reversible Sorting Algorithm [Original Paper Implementation]

Implementing the 1994 report "A Block Sorting Lossless Data Compression Algorithm"

Quick Intro

LeetArxiv is Leetcode for implementing Arxiv papers and other technical reports.

Frontmatter for the 1994 technical report: A Block Sorting Lossless Data Compression Algorithm

1.0 Introduction

Burrows-Wheeler is a reversible sorting algorithm. That is, one can go from sorted to unsorted form. The algorithm is central to the BZIP2¹ compression utility.

In the article below, we looked at BZIP2’s superiority in Elon Musk’s compression challenge:

Decreasing Uniformity : Neuralink Compression Challenge Submission

Burrows-Wheeler was published in the 1994 technical report: A Block Sorting Lossless Data Compression Algorithm (Burrows & Wheeler, 1994)² and the paper is 24 pages long.

As usual, we code only the important parts of the paper.

2.0 Coding Burrows-Wheeler

The typical Burrows-Wheeler implementation is split into two parts: a forward transformation and a reversible transformation.

*The paper calls the forward transformation the Compression transformation and the reversible transformation a Decompression transformation.

2.1 Forward/Compression Transformation

Compression transformation introduced on Page 2

The forward transform is pretty simple. Here’s a no-fluff summary with an example:

---

Forward Step in Burrows-Wheeler Example

• Step 1: Append a special character at the end of an input array.

  *The special character is elucidated in (Langmead, 2000)³

  **The original paper opts to send the sorted array as well as its lexicographic index for reversibility.

  • Let our input be the array [5, 12, 4, 3, 7, 2] of length 6.

  • Appending a special character modifies the array to [5, 12, 4, 3, 7, 2, $]

  • The special character must satisfy these properties:

    • Occurs nowhere else in the text.

    • Has a value less than all other characters in the array.

• Step 2: Rotate the input array by n times. n is the length of the modified array.

  • n is equal to 7 for the modified array [5, 12, 4, 3, 7, 2, $].

  • The 7 rotations of our array are :



• Step 3: Sort the rotation lexicographically. This means sorting the array of rotations from smallest to largest by comparing their indices.



• Step 4: Take the last column as the output.

  • Output is [2,7,4,12,$, 3, 5]

---

In Python (Langmead, 2000):

def rotations(t):
""" Return list of rotations of input string t """
    tt = t * 2
    return [ tt[i:i+len(t)] for i in xrange(0, len(t)) ]

def bwm(t):
""" Return lexicographically sorted list of t’s rotations """
    return sorted(rotations(t))

def bwtViaBwm(t):
""" Given T, returns BWT(T) by way of the BWM """
    return ''.join(map(lambda x: x[-­‐1], bwm(t)))

2.2 Reverse/Decompression Transformation

Reverse sorting is introduced on Page 4

The reverse algorithm builds a list of predecessor characters. Here’s the paper summary with no-fluff:

---

Reverse Step in Burrows-Wheeler Example for Output [2,7,4,12,$, 3, 5]

• Step 1: Create a table with two columns.

  • The first column is the sorted output.

  • The second column is the original output.



• Step 2: Use predecessor characters to map the Last to the First character across columns.

  • Initialize an empty array and place $ to get [$]

  • $ in first column occurs at index 4 on second column where the value is 5.

    • Place 5 at the front of our array [5,$].

  • Find 5 in column 2. Observe that it maps to 12 in column 1.

    • Place 12 at the front of our array [12, 5,$].

  • Find 12 in column 2. Observe that it maps to 4 in column 1.

    • Place 4 at the front of our array [4,12, 5,$].

  • Find 4 in column 2. Observe that it maps to 3 in column 1.

    • Place 3 at the front of our array [3,4,12, 5,$].

  • Find 3 in column 2. Observe that it maps to 7 in column 1.

    • Place 7 at the front of our array [7,3,4,12, 5,$].

  • Find 7 in column 2. Observe that it maps to 2 in column 1.

    • Place 2 at the front of our array [2, 7, 3,4,12, 5,$].

• Step 4: Reverse the array to get the original input

  • Reversal output becomes [$ , 5 , 12 , 4 , 3 , 7 , 2]

  • This matches the original input [5, 12, 4, 3, 7, 2, $].

---

In Python, it can be written as

def inverse_bwt(bwt):
    if not bwt:
        return ""

    #Initialize the 2-column table
    table = list(zip(bwt, range(len(bwt))))

    #Sort to get the first column (F)
    F = sorted(table, key=lambda x: (x[0], x[1]))

    # Reconstruct the original string
    row = bwt.index('$')
    original = []

    for _ in range(len(bwt) - 1):
        char, row = F[row]  #Get next character and row
        original.append(char)

    # Reverse to get original order (since we built it backward)
    return original[::-1] + ['$']

Burrows-wheeler is used for data compression. Let me know if you use it anywhere else.
